Specifications:

Capacity

t

10,20,25,30,40,50

Safe overload

%FS

150

Ultimate overload

%FS

300

Rated output

mV/V

1.5 ± 0.002

Excitation voltage

Vdc

9 ~ 12

Combined error

%FS

± 0.05

Zero unbalance

%FS

± 1

Non-linearity

%FS

± 0.05

Hysteresis

%FS

± 0.05

Repeatability

%FS

± 0.03

Creep

%FS/30min

± 0.03

Input resistance

Ω

700 ± 10

Output resistance

Ω

700 ± 5

Insulation resistance

M Ω

≥ 5000 @ 100 Vdc

Operating temperature range

℃

-35 ~ +65

Compensated temperature range

℃

-10 ~ +40

Temperature coefficient of SPAN

%FS/10℃

± 0.02

Temperature coefficient of ZERO

%FS/10℃

± 0.03
